IEC 62358:2012

Ferrite cores - Standard inductance factor for gapped cores and its tolerance

Circulation Date: 2012-10
Edition: 2.0
Language: EN-FR - bilingual english/french
Seitenzahl: 36 VDE Artno.: 219277

Content

IEC 62358:2012 provides standard AL values (inductance factors) and their tolerances of Pot, RM, ETD, E, EER, EP, PQ and low-profile gapped ferrite cores. This edition includes the following significant technical changes with respect to the previous editions:
a) addition of AL value (inductance factor) and its tolerance for PQ-cores;
b) addition of AL value (inductance factor) and its tolerance for EFD-cores;
c) addition of AL value (inductance factor) and its tolerance for Low-profile ER-I-cores;
d) addition of AL value (inductance factor) and its tolerance for Low-profile ER-cores (ER9,5 x 2,5 x 5, ER11 x 2,5 x 6, ER14,5 x 3 x 7 ferrite cores are same as the previous edition);
e) addition of AL value (inductance factor) and its tolerance for Low-profile PQ-I-cores.
