IEC 61169-38:2008

Radio-frequency connectors - Part 38: Sectional specification - Radio frequency coaxial connectors model, slide-in (rack and panel applications) - Characteristic impedance 50 O (type TMA) - 50 O applications

Circulation Date: 2008-11
Edition: 1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 53 VDE Artno.: 220489

Content

IEC 61169-38:2008 which is a sectional specification, provides information and rules for the preparation of detail specifications for series TMA r.f. connectors together with the pro forma blank detail specification. Series TMA connectors have a characteristic impedance of 50 O and are normally used with R.F cables or with microstrip in microwave fields that has a blind-entry and middle low-power. The connectors are usable up to a frequency of at least 6 GHz.
