IEC 60214-1:2014

Tap-changers - Part 1: Performance requirements and test methods

Circulation Date: 2014-05
Edition: 2.0
Language: EN-FR - bilingual english/french
Seitenzahl: 156 VDE Artno.: 221347

Content

IEC 60214-1:2014 applies to on-load tap-changers of both resistor and reactor types, de-energized tap-changers, and their motor-drive mechanisms. It applies mainly to tap-changers immersed in mineral insulating oil according to IEC 60296 but may also be used for tap-changers with air or gas insulation or immersed in other insulating liquids insofar as conditions are applicable. It applies mainly to tap-changers with arcing contacts but may also be used for arcing-free on-load tap-changers (such as electronic switching) insofar as conditions are applicable. This part of IEC 60214 applies to power and distribution transformers of all types and also to reactors. It does not apply to transformers and reactors mounted on railway rolling stock. This second edition cancels and replaces the first edition published in 2003. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a) incorporation of requirements on vacuum type on-load tap-changers,
b) incorporation of requirements on gas insulated tap-changers,
c) changes in the type tests to fit with the service conditions,
d) reference to the newest edition of IEC 60076-3:2013.
