IEC 60317-0-9:2015

Specifications for particular types of winding wires - Part 0-9: General requirements - Enamelled rectangular aluminium wire

Circulation Date: 2015-05
Edition: 1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 47 VDE Artno.: 221743


IEC 60317-0-9:2015 specifies the general requirements of enamelled rectangular aluminium winding wires. The range of nominal conductor dimensions is given in the relevant specification sheet. When reference is made to a winding wire according to a standard of the IEC 60317 series mentioned under Clause 2, the following information is given in the description:
- reference to IEC specification;
- nominal conductor dimensions in millimetres (width thickness);
- grade. EXAMPLE - IEC 60317-16 - 4,00 x 1,00 Grade 1 Keywords: enamelled rectangular aluminium winding wires, insulated wires used for windings in electrical equipment
