IEC 62433-3:2017

EMC IC modelling - Part 3: Models of integrated circuits for EMI behavioural simulation - Radiated emissions modelling (ICEM-RE)

Circulation Date: 2017-01
Edition: 1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 181 VDE Artno.: 224229

Content

IEC 62433-3:2017 provides a method for deriving a macro-model to allow the simulation of the radiated emission levels of an Integrated Circuit (IC). This model is commonly called Integrated Circuit Emission Model - Radiated Emission, ICEM-RE.  The model is intended to be used for modelling a complete IC, with or without its associated package, a functional block and an Intellectual Property (IP) block of both analogue and digital ICs (input/output pins, digital core and supply), when measured or simulated data cannot be directly imported into simulation tools.
