IEC 62946-01:2018
Connectors for electrical and electronic equipment - Part 01: Rectangular connectors - Detail specification for 8-way, shielded, free and fixed high density connectors for data transmission with frequencies up to 100 MHz and with current carring capacity up to 1A
Circulation Date:
2018-05
Edition:
1.0
Language: EN - english
Seitenzahl: 29 VDE Artno.: 225657
IEC 62946-01:2018(E) covers 8-way shielded connectors, and is intended to specify the common dimensions, mechanical, electrical and environmental characteristics and tests for the family of IEC 62946-01 connectors.
These connectors are intermateable and interoperable with other IEC 62946 series connectors.
Key words: Connectors, Rectangular, 8-way, Shielded Free and Fixed High density, Data Transmission
The contents of the corrigendum of March 2020 have been included in this copy.
