IEC 61300-3-14:2014
Fibre optic interconnecting devices and passive components - Basic test and measurement procedures - Part 3-14: Examinations and measurements - Error and repeatability of the attenuation settings of a variable optical attenuator
Circulation Date:
2014-10
Edition:
3.0
Language: EN-FR - bilingual english/french
Seitenzahl: 24 VDE Artno.: 248045
IEC 61300-3-14:2014 provides a method to measure the error and repeatability of the attenuation value settings of a variable optical attenuator (VOA). There are two control technologies for VOAs, manually controlled and electrically controlled. This standard covers both control technologies of VOAs and also covers both single-mode and multimode fibre VOAs. This third edition cancels and replaces the second edition published in 2006 and constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
- title modification replacing the word 'accuracy' by 'error';
- inclusion of the distinction of manually and electrically controlled variable optical attenuators in the Scope;
- revision of clauses for apparatus and details to be specified to harmonize with other standards in the IEC 61300 series;
- addition of 'the maximum deviation of attenuation from setting' to the clause for calculation;
- addition of 'measurement method of hysteresis characteristics' in Annex B. Keywords: attenuation value settings, variable optical attenuator (VOA)
