IEC 60076-22-7:2020

Power transformers - Part 22-7: Power transformer and reactor fittings - Accessories and fittings

Circulation Date: 2020-05
Edition: 1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 127 VDE Artno.: 248718

Content

IEC 60076-22-7:2020 applies to a selection of accessories and fittings mounted on liquid immersed power transformers according to IEC 60076-1 and reactors according to IEC 60076­6 with or without conservator for indoor or outdoor installation. It outlines the service conditions and the mechanical requirements that are common to all the accessories and fittings. This document also outlines the operation requirements specific to each device as well as the preferred dimensions relevant for interchangeability and the type and routine test to be performed.This document covers an exhaustive selection of the accessories and fittings that are currently used on transformers or reactors.
The contents of the corrigendum of June 2023 have been included in this copy.
