IEC 61169-60:2021
Radio-frequency connectors - Part 60: Sectional specification for RF coaxial connectors with push on mating - Characteristic impedance 50 Ohm (type SMPM)
Circulation Date:
2021-03
Edition:
1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 61 VDE Artno.: 249769
IEC 61169-60:2021 provides information and rules for the preparation of detail specifications (DS) for RF coaxial connectors with push-on coupling, typically for use in 50 ? RF cables or micro-strips in microwave, telecommunication, wireless systems and other fields (SMPM).
It specifies mating face dimensions for general purpose connectors – grade 2, dimensional details of standard test connectors-grade 0, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series SMPM RF connectors.
This specification indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.
