IEC 61169-71:2022
Radio-frequency connectors - Part 71: Sectional specification for RF coaxial connectors with inner diameter of outer conductor 5,0 mm - Characteristic impedance 50 Ohms (type NEX10®)
Circulation Date:
2022-05
Edition:
1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 66 VDE Artno.: 250924
IEC 61169-71:2022, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for RF coaxial connector, typically for use in 50 O radio communication systems, type NEX10® .
This document describes mating face dimensions for general purpose connectors (grade 2), dimensional details of standard test connectors (grade 1), gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to type NEX10® RF coaxial connectors.
This document indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.
