IEC TS 60034-25:2022

Rotating electrical machines - Part 25: AC electrical machines used in power drive systems - Application guide

Circulation Date: 2022-06
Edition: 4.0
Language: EN - english
Seitenzahl: 107 VDE Artno.: 250995


IEC TS 60034-25:2022 describes the performance characteristics of AC electrical machines for use on converter supplies. For electrical machines specifically designed for converter duty application design features are defined. It also specifies the interface parameters and interactions between the electrical machine and the converter including installation guidance as part of a power drive system, but except for the voltage at the power interface which is described in IEC TS 61800-8. This fourth edition of IEC TS 60034-25 cancels and replaces the third edition, This edition includes the following significant technical changes with respect to the previous edition:
a. The definitions of a converter capable motor and a converter duty motor are added.
b. Clause 18 modified to include the performance expectations of a converter capable motor.
c. Clause 8 modified to update shaft currents section.
d. Annex D added to define the derating requirements.
