IEC 62228-6:2022

Integrated circuit - EMC evaluation of transceivers - Part 6: PSI5 transceivers

Circulation Date: 2022-11
Edition: 1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 99 VDE Artno.: 251333

Content

IEC 62228-6:2022 specifies test and measurement methods for EMC evaluation of peripheral sensor interface 5 (PSI5) transceiver integrated circuits (ICs) under network condition. It defines test configurations, test conditions, test signals, failure criteria, test procedures, test setups and test boards. It is applicable for PSI5 satellite ICs (e.g. sensors) and ICs with embedded PSI5 transceivers (e.g. PSI5 electronic control unit IC). The document covers
the emission of RF disturbances,
the immunity against RF disturbances,
the immunity against impulses, and
the immunity against electrostatic discharges (ESD).
