IEC 61980-3:2022

Electric vehicle wireless power transfer (WPT) systems - Part 3: Specific requirements for magnetic field wireless power transfer systems

Circulation Date: 2022-11
Edition: 1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 239 VDE Artno.: 251385


IEC 61980-3:2022 applies to the off-board supply equipment for wireless power transfer via magnetic field (MF-WPT) to electric road vehicles for purposes of supplying electric energy to the RESS (rechargeable energy storage system) and/or other on-board electrical systems. The MF-WPT system operates at standard supply voltage ratings per IEC 60038 up to 1 000 V AC and up to 1 500 V DC from the supply network. The power transfer takes place while the electric vehicle (EV) is stationary.
Off-board supply equipment fulfilling the requirements in this document are intended to operate with EV devices fulfilling the requirements described in ISO 19363.
The aspects covered in this document include
– the characteristics and operating conditions,
– the required level of electrical safety,
– requirements for basic communication for safety and process matters if required by a MF WPT system,
– requirements for positioning to assure efficient and safe MF-WPT power transfer, and
– specific EMC requirements for MF-WPT systems.
The following aspects are under consideration for future documents:
– requirements for MF-WPT systems for two- and three-wheel vehicles,
– requirements for MF-WPT systems supplying power to EVs in motion,
– requirements for bidirectional power transfer,
– requirements for flush mounted primary device,
– requirements for MF-WPT systems for heavy duty vehicle, and
– requirements for MF-WPT systems with inputs greater than 11,1 kVA.
This document does not apply to
– safety aspects related to maintenance, and
– trolley buses, rail vehicles and vehicles designed primarily for use off-road.
IEC 61980-3:2022 is to be used in conjunction with IEC 61980-1:2020.
