IEC TS 61156-1-2:2023
Multicore and symmetrical pair/ quad cables for digital communications - Part 1-2: Electrical transmission characteristics and test methods of symmetrical pair/ quad cables
Circulation Date:
2023-11
Edition:
1.0
Language: EN - english
Seitenzahl: 74 VDE Artno.: 252340
IEC TS 61156-1-2:2023 specifies symmetrical pair/quad electrical transmission characteristics and test methods present in IEC 61156-1:2002 (Edition 2) and not carried into IEC 61156-1:2007 (Edition 3). It details characteristic impedance test methods and function fitting procedures, the open/short-circuit method and the background of unbalance attenuation measurement.
It is extended by a description of the balunless measurements technique, which is an amendment to the former technical report and is improved and incorporated into this new edition. The complete document is transferred into a technical specification.
