IEC 60191-6-2:2001
Mechanical standardization of semiconductor devices - Part 6-2: General rules for the preparation of outline drawings of surface mounted semiconductor devices packages - Design guide for 1,50 mm, 1,27 mm and 1,00 mm pitch ball and column terminal packages
Circulation Date:
2001-12
Edition:
1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 21 VDE Artno.: 219483
IEC 60191-6-2:2001 covers the requirements for the preparation of drawings of integrated circuit outlines for the various ball terminal packages, e.g. ceramic ball grid array (C-BGA), plastic ball grid array (P-BGA), tape ball grid array (T-BGA) and others as well as column terminal packages, e.g. ceramic column grid array (C-CGA).
