IEC 61169-1-4:2020

Radio-frequency connectors - Part 1-4: Electrical test methods - Voltage standing wave ratio, return loss and reflection coefficient

Circulation Date: 2020-07
Edition: 1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 26 VDE Artno.: 248936

Content

IEC 61169-1-4:2020 provides test methods for the voltage standing wave ratio, return loss and reflection coefficient of RF connectors, including frequency domain method, time domain method, and gating.
This document is applicable to cable RF connectors, microstrip RF connectors and RF adapters. It is also suitable to RF channels in multi-RF channel connectors and hybrid connectors.
