IEC 61076-3-114:2009

Connectors for electronic equipment - Product requirements - Part 3-114: Rectangular connectors - Detail specification for protective housings for use with 8-way shielded and unshielded connectors for frequencies up to 600 MHz for industrial environments incorporating the IEC 60603-7 series interface - Variant 11 related to IEC 61076-3-106 - Bayonet coupling type

Ausgabedatum: 2009-04
Edition: 1.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 47 VDE-Artnr.: 216441


IEC 61076-3-114:2009 covers protective housings for upgrading existing 8-way shielded and unshielded connectors utilizing the interface described in IEC 60603-7-2, IEC 60603-7-3, IEC 60603-7-4, IEC 60603-7-5, and IEC 60603-7-7 to IP65 and IP67 ratings, according to IEC 60529, for use in industrial environments. The housings cover a variety of different locking mechanisms and a variety of different mounting configurations and termination types which are detailed in IEC 60603-7.
