IEC 60534-2-4:2009
Industrial-process control valves - Part 2-4: Flow capacity - Inherent flow characteristics and rangeability
Ausgabedatum:
2009-05
Edition:
2.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 20 VDE-Artnr.: 216475
IEC 60534-2-4:2009 applies to all types of industrial-process control valves. It defines how to state typical control valve inherent flow characteristics and inherent rangeabilities. It also defines how to establish criteria for adherence to manufacturer-stated flow characteristics. This edition constitutes a technical revision. The main changes with respect to the previous edition are:
- update the normative references;
- delete the terminology included in IEC 60534-1;
- transform the previous Note 1 in Clause 6;
- redraw the graphics;
- delete the previous Figure 3.
