IEC 60252-1:2010

AC motor capacitors - Part 1: General - Performance, testing and rating - Safety requirements - Guidance for installation and operation

Ausgabedatum: 2010-09
Edition: 2.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 61 VDE-Artnr.: 217541


IEC 60252-1:2010 applies to motor capacitors intended for connection to windings of asynchronous motors supplied from a single-phase system having a frequency up to and including 100 Hz, and to capacitors to be connected to three-phase asynchronous motors so that these motors may be supplied from a single-phase system. This standard covers impregnated or unimpregnated capacitors having a dielectric of paper, plastic film, or a combination of both, either metallized or with metal-foil electrodes, with rated voltages up to and including 660 V. This edition includes the following significant technical changes with respect to the previous edition:
- the definition of "segmented capacitors" has been added in 3.6;
- the definition of "classes of operation" has been clarified, with the addition of the concept of "probable life" with reference to statistics, in 3.9;
- the following wording "Operation above the rated voltage will reduce the life expectancy of the capacitor" has been introduced in 6.1.
- some clarifications have been added to Clause 8, Marking, mainly for small capacitors.
