Cover IEC 80416-3:2002+AMD1:2011 CSV (Consolidated Version)
größer

IEC 80416-3:2002+AMD1:2011 CSV (Consolidated Version)

Basic principles for graphical symbols for use on equipment - Part 3: Guidelines for the application of graphical symbols

Ausgabedatum: 2011-10
Edition: 1.1
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 28 VDE-Artnr.: 218328

Inhaltsverzeichnis

IEC 80416-3:2002+A1:2011 provides guidelines for the application of graphical symbols for use on equipment in order to maintain visual clarity and overall consistency when such graphical symbols are applied. It stipulates the permissible extent by which a symbol original may be modified in reproduction for actual use on equipment. It bears the edition number 1.1. The technical content is therefore identical to the base edition and its amendment and has been prepared for user convenience. A vertical line in the margin shows where the base publication has been modified by amendment 1. Additions and deletions are displayed in red, with deletions being struck through. This consolidated version consists of the first edition (2002) and its amendment 1 (2011). Therefore, no need to order amendment in addition to this publication.
