IEC 60679-3:2012
Quartz crystal controlled oscillators of assessed quality - Part 3: Standard outlines and lead connections
Ausgabedatum:
2012-12
Edition:
3.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 49 VDE-Artnr.: 219508
IEC 60679-3:2012 specifies the outline dimensions and lead connections for quartz crystal controlled oscillators with lead enclosures. This edition includes the following significant technical changes with respect to the previous edition:
- CO 01, CO 07, CO 10, CO 17 and CO 18 were deleted;
- The current pin layout of CO 06 was deleted. And new pin layout of CO 06 was added as CO 40;
- New layout of CO 15 was added as CO 41;
- Two new enclosures, CO 42 and CO 43 were added. Therefore revised edition includes 15 types of enclosures as in Table 1 of Clause 5.
