IEC/IEEE 60255-118-1:2018

Measuring relays and protection equipment - Part 118-1: Synchrophasor for power systems - Measurements

Ausgabedatum: 2018-12
Edition: 1.0
Sprache: EN - englisch
Seitenzahl: 74 VDE-Artnr.: 247031

Inhaltsverzeichnis

IEC/IEEE 60255-118-1:2018 is used for synchronized phasor measurement systems in power systems. It defines a synchronized phasor (synchrophasor), frequency, and rate of change of frequency measurements. It describes time tag and synchronization requirements for measurement of all three of these quantities. It specifies methods for evaluating these measurements and requirements for compliance with the standard under both static and dynamic conditions. It defines a phasor measurement unit (PMU), which can be a stand-alone physical unit or a functional unit within another physical unit. This document does not specify hardware, software or a method for computing phasors, frequency, or rate of change of frequency.
