IEC 62228-3:2019

Integrated circuits - EMC evaluation of transceivers - Part 3: CAN transceivers

Ausgabedatum: 2019-03
Edition: 1.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 156 VDE-Artnr.: 247242

Inhaltsverzeichnis

IEC 62228-3:2019 specifies test and measurement methods for EMC evaluation of CAN transceiver ICs under network condition. It defines test configurations, test conditions, test signals, failure criteria, test procedures, test setups and test boards. It is applicable for CAN standard transceivers, CAN transceivers with partial networking functionality and CAN transceivers with flexible data rate capability and covers
- the emission of RF disturbances,
- the immunity against RF disturbances,
- the immunity against impulses, and
- the immunity against electrostatic discharges (ESD).
This first edition cancels and replaces the first edition of IEC TS 62228 published in 2007 and constitutes a technical revision. This edition includes the following significant technical changes with respect to IEC TS 62228:
a) introduction of CAN transceivers with partial networking functionality and CAN transceivers with flexible data rate capability and addition of operation modes and test descriptions in the respective subclauses of the document;
b) introduction of minimal communication network with two CAN transceivers;
c) update of the test requirements and targets in Annex C;
d) addition of Annex D for common mode choke characterization.
