IEC 60512-27-200:2022

Connectors for electrical and electronic equipment - Tests and measurements - Part 27-200: Additional specifications for signal integrity tests up to 2 000 MHz on IEC 60603-7 series connectors - Tests 27a to 27g

Ausgabedatum: 2022-09
Edition: 1.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 59 VDE-Artnr.: 251158

Inhaltsverzeichnis

IEC 60512-27-200:2022 is primarily intended for use in signal integrity and transmission performance testing up to 2 000 MHz of IEC 60603-7 series 8-way connector type IEC 60603-7-81, according to connector test method IEC 60512-28-100.
This part of IEC 60512 covers additional, supplemental test method specifications to extend the upper frequency for the test connectors and associated indirect-reference test fixtures used in the signal integrity and transmission performance tests specified in IEC 60512-27-100. In support of de-embedded crosstalk and related transmission requirements specified in IEC 60603-7-81, for frequencies up to 2 000 MHz, these supplemental specifications extend the upper test frequency from IEC 60512-27-100 up to 500 MHz to the upper test frequency of IEC 60512-28-100 up to 2 000 MHz. This document covers measurements of connector signal integrity and transmission performance of 8-way connector types defined in these published connector series standards:
- IEC 60603-7-2
- IEC 60603-7-3
- IEC 60603-7-4
- IEC 60603-7-5
- IEC 60603-7-41
- IEC 60603-7-51
- IEC 60603-7-81.
This document covers respective performance test procedures of connector signal integrity and transmission performance defined in these published connector test method series standards:
- IEC 60512-26-100
- IEC 60512-27-100
- IEC 60512-28-100.
