IEC TR 63358-1:2023
Graphical symbols for diagrams - Part 1: General, qualifying and generic symbols
Ausgabedatum:
2023-02
Edition:
1.0
Sprache: EN - englisch
Seitenzahl: 46 VDE-Artnr.: 251535
IEC TR 63358-1:2023 contains, by way of example, a collection of generic symbols, general symbols and qualifying symbols for diagrams taken from IEC 60617. Some of the wording of entries in the IEC 60617 database are annotated and/or modified for the purpose of clarification. Existing symbols in the IEC 60617 database are classified according to the classification proposed in this document.
