IEC 60317-89:2023
Specifications for particular types of winding wires - Part 89: Polyesterimide enamelled round aluminum wire, class 200
Ausgabedatum:
2023-07
Edition:
1.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 20 VDE-Artnr.: 252047
IEC 60317-89:2023 specifies the requirements of enamelled round aluminium winding wire of class 200 with a sole coating based on polyesterimide resin, which can be modified providing it retains the chemical identity of the original resin and meets all specified wire requirements. NOTE A modified resin is a resin that has undergone a chemical change, or contains one or more additives to enhance certain performance or application characteristics. The range of nominal conductor diameters covered by this standard is as follows:
grade 1: 0,250 mm up to and including 1,600 mm;
grade 2: 0,250 mm up to and including 5,000 mm.
The nominal conductor diameters are specified in Clause 4 of IEC 60317-0-3:2008 and IEC 60317-0-3:2008/AMD1:2013. This International Standard is to be used in conjunction with IEC 60317-0-3:2008, its Amendment 1 (2013) and its Amendment 2 (2019).
