IEC 62751-2:2014+AMD1:2019+AMD2:2023 CSV (Consolidated Version)

Power losses in voltage sourced converter (VSC) valves for high-voltage direct current (HVDC) systems - Part 2: Modular multilevel converters

Ausgabedatum: 2023-08
Edition: 1.2
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 252 VDE-Artnr.: 252104

Inhaltsverzeichnis

IEC 62751-2:2014+AMD1:2019+AMD2:2023 gives the detailed method to be adopted for calculating the power losses in the valves for an HVDC system based on the 'modular multi-level converter', where each valve in the converter consists of a number of self-contained, two-terminal controllable voltage sources connected in series. It is applicable both for the cases where each modular cell uses only a single turn-off semiconductor device in each switch position, and the case where each switch position consists of a number of turn-off semiconductor devices in series (topology also referred to as 'cascaded two-level converter'). The main formulae are given for the two-level 'half-bridge' configuration but guidance is also given as to how to extend the results to certain other types of MMC building block configuration.
