Cover IEC 60076-4:2002

IEC 60076-4:2002

Power transformers - Part 4: Guide to the lightning impulse and switching impulse testing - Power transformers and reactors

Ausgabedatum: 2002-06
Edition: 1.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 123 VDE-Artnr.: 201037


Gives guidance and explanatory comments on the existing procedures for lightning and switching impulse testing of power transformers to supplement the requirements of IEC 60076-3. Also generally applicable to the testing of reactors (see IEC 60289), modifications to power transformer procedures being indicated where required. Information is given on waveshapes, test circuits including test connections, earthing practices, failure detection methods, test procedures, measuring techniques and interpretation of results.
