Cover IEC 60076-5:2006

IEC 60076-5:2006

Power transformers - Part 5: Ability to withstand short circuit

Ausgabedatum: 2006-02
Edition: 3.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 71 VDE-Artnr.: 212554


Identifies the requirements for power transformers to sustain without damage the effects of overcurrents originated by external short circuits. Describes the calculation procedures used to demonstrate the thermal ability of a power transformer to withstand such overcurrents and both the special test and the theoretical evaluation method used to demonstrate the ability to withstand the relevant dynamic effects.
