IEC 60512-26-100:2008
Connectors for electronic equipment - Tests and measurements - Part 26-100: Measurement setup, test and reference arrangements and measurements for connectors according to IEC 60603-7 - Tests 26a to 26g
Ausgabedatum:
2008-07
Edition:
1.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 113 VDE-Artnr.: 214799
IEC 60512-26-100:2008 specifies the test and measurements and the related measurement setup and reference arrangements for interoperability and backward compatibility tests for the development and qualification of 8-way, free and fixed connectors for data transmission. The following test methods are provided:
- insertion loss, test 26a;
- return loss, test 26b;
- near-end crosstalk (NEXT), test 26c;
- far-end crosstalk (FEXT), test 26d;
- transfer impedance, test 26e;
- transverse conversion loss (TCL), test 26f;
- transverse conversion transfer loss (TCTL), test 26g.
This publication is to be read in conjunction with IEC 60512-1:2001 and IEC 60512-1-100:2006.
