Connectors for electronic equipment - Part 7-41: Detail specification for 8-way, unshielded, free and fixed connectors, for data transmissions with frequencies up to 500 MHz
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 28 VDE-Artnr.: 216906
IEC 60603-7-41:2010 covers 8-way, unshielded, free and fixed connectors, references dimensional, mechanical, electrical and environmental characteristics and tests in IEC 60603-7, and specifies electrical transmission requirements, including power sum alien (exogenous) crosstalk, for frequencies up to 500 MHz. These connectors are intermateable and interoperable with other IEC 60603-7 series connectors as defined in clause 2 of IEC 60603-7. These connectors are backward compatible with other IEC 60603-7 series connectors.
