Cover IEC 60512-15-2:2018
größer

IEC 60512-15-2:2018

Connectors for electrical and electronic equipment - Tests and measurements - Part 15-2: Connector tests (mechanical) - Test 15b: Insert retention in housing (axial)

Ausgabedatum: 2018-01
Edition: 2.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 16 VDE-Artnr.: 225260

Inhaltsverzeichnis

IEC 60512-15-2:2018 This part of IEC 60512, when required by the detail (product) specification, is used for testing connectors within the scope of technical committee 48. It may also be used for similar devices when specified in a detail (product) specification.
The object of this document is to detail a standard test method to assess the effectiveness of the retaining system of a connector insert within a connector housing to withstand axial forces likely to be encountered during normal use, i.e. the highest insertion and withdrawal forces into/from a mating counterpart, without the connector insert being dislodged from the connector housing.
The test method detailed in this document is a companion to the one detailed in IEC 60512-15-3
This second edition cancels and replaces the first edition, published in 2008. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition: the test method B (pressure method) suitable for testing hermetic connector has been added. This edition reflects IEC 60512-1-101, Blank detail specification.
Keywords: Connectors, Connector Tests, Insert Retention
