IEC 60317-82:2020

Specifications for particular types of winding wires - Part 82: Polyesterimide enamelled rectangular copper wire, class 200

Ausgabedatum: 2020-06
Edition: 1.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 18 VDE-Artnr.: 248821

Inhaltsverzeichnis

IEC 60317-82: 2020 specifies the requirements of enamelled rectangular copper winding wires of class 200 with a sole coating based on polyesterimide resin, which can be modified provided it retains the chemical identity of the original resin and meets all specified wire requirements.
NOTE A modified resin is a resin that has undergone a chemical change or contains one or more additives to enhance certain performance or application characteristics.
The range of nominal conductor dimensions covered by this document is:

  • width: min. 2,0 mm max. 16,0 mm;
  • thickness: min. 0,80 mm max. 5,60 mm.
Wires of grade 1 and grade 2 are included in this specification and apply to the complete range of conductors. The specified combinations of width and thickness as well as the specified width/thickness ratio are given in IEC 60317-0-2.
