IEC 61169-15:2021

Radio-frequency connectors - Part 15: Sectional specification - RF coaxial connectors with inner diameter of outer conductor 4,13 mm (0,163 in) with threaded coupling - Characteristic impedance 50 O (type SMA)

Ausgabedatum: 2021-01
Edition: 1.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 50 VDE-Artnr.: 249585

Inhaltsverzeichnis

IEC 61169-15:2021 provides information and rules for the preparation of detail specifications (DS) for RF coaxial connectors with inner diameter of outer conductor 4,13 mm (0,163 in) with threaded coupling with a characteristic impedance of 50 O (type SMA).
This document specifies mating face dimensions for high performance connectors Í grade 1, dimensional details of standard test connectors Í grade 0, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series SMA RF connectors.
This document indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.
