IEC 60747-5-6:2021 RLV
Semiconductor devices - Part 5-6: Optoelectronic devices - Light emitting diodes
Sprache: EN - englisch
Seitenzahl: 198 VDE-Artnr.: 250089
IEC 60747-5-6:2021 RLV contains both the official IEC International Standard and its Redline version. The Redline version is available in English only and provides you with a quick and easy way to compare all the changes between the official IEC Standard and its previous edition.
IEC 60747-5-6:2021 specifies the terminology, the essential ratings and characteristics, the measuring methods and the quality evaluations of light emitting diodes (LEDs) for general industrial applications such as signals, controllers, sensors, etc.
LEDs for lighting applications are out of the scope of this part of IEC 60747.
LEDs are classified as follows:
- LED package;
- LED flat illuminator;
- LED numeric display and alpha-numeric display;
- LED dot-matrix display;
- infrared-emitting diode (IR LED);
- ultraviolet-emitting diode (UV LED).
LEDs with a heat spreader or having a terminal geometry that performs the function of a heat spreader are within the scope of this part of IEC 60747.
An integration of LEDs and controlgears, integrated LED modules, semi-integrated LED modules, integrated LED lamps or semi-integrated LED lamps, are out of the scope of this part of IEC 60747. This edition includes the following significant technical changes with respect to the previous edition:
- ultraviolet-emitting diodes (UV LED) and their related technical contents were added;
- power efficiency (?PE) as part of electrical and optical characteristics were added;
- new measuring methods related to thermal resistance were added;
- hydrogen sulphide corrosion test was added to quality evaluation;
- some standards were added to the bibliography.
