IEC 61280-1-4:2023 RLV
Fibre optic communication subsystem test procedures - Part 1-4: General communication subsystems - Light source encircled flux measurement method
Ausgabedatum:
2023-01
Edition:
3.0
Sprache: EN - englisch
Seitenzahl: 96 VDE-Artnr.: 251501
IEC 61280-1-4:2023 RLV contains both the official IEC International Standard and its Redline version. The Redline version is available in English only and provides you with a quick and easy way to compare all the changes between the official IEC Standard and its previous edition.
IEC 61280-1-4:2023 establishes the characterization process of the encircled flux measurement method of light sources intended to be used with multimode fibre. This document sets forth a procedure for the collection of two-dimensional fibre optic nearfield greyscale data and subsequent reduction to one-dimensional data expressed as a set of three sampled parametric functions of radius from the fibre’s optical centre. Estimation of the fibre core diameter is not an objective of this document. This third edition cancels and replaces the second edition published in 2009. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
- improvement of calibration procedure and calibration traceability;
- improvement of fibre shaker description and requirements;
- addition of pulsed light sources;
- removal of a poorly traceable calibration process using a micro positioner.
