IEC 60749-10:2022

Semiconductor devices - Mechanical and climatic test methods - Part 10: Mechanical shock - device and subassembly

Ausgabedatum: 2022-04
Edition: 2.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 24 VDE-Artnr.: 250850

Inhaltsverzeichnis

IEC 60749-10:2022 is intended to evaluate devices in the free state and assembled to printed wiring boards for use in electrical equipment. The method is intended to determine the compatibility of devices and subassemblies to withstand moderately severe shocks. The use of subassemblies is a means to test devices in usage conditions as assembled to printed wiring boards. Mechanical shock due to suddenly applied forces, or abrupt change in motion produced by handling, transportation or field operation can disturb operating characteristics, particularly if the shock pulses are repetitive. This is a destructive test intended for device qualification.
This edition cancels and replaces the first edition published in 2002. This edition includes the following significant technical changes with respect to the previous edition:

  1. covers both unattached components and components attached to printed wiring boards;
  2. tolerance limits modified for peak acceleration and pulse duration;
  3. mathematical formulae added for velocity change and equivalent drop height.
